Frp grating walkway is manufactured by laying continuous glass fibres in the mould in the direction of vertical and horizontal, and thurougly wetted out with resin, layer by layer. When the weaving process is completed, the mould is heated to cure the panel. After curing, the panel is ejected from the mould. The standard panel would have meniscus (concave) top surface. Any process such as post applied grit could be bonded after as a secondary operation. This continuous process produces an integral, one piece panel, which offers excellent corrosion resistance as well as bi-directional strength.
|
Essential details |
|
|
Place of Origin |
Xiamen,China |
|
Brand Name |
Yujinxiang |
|
Product Name |
Frp grating walkway |
|
Material |
Fiberglass, resin, calcium, color toner |
|
Surface Treatment |
Smooth, concave, gritted |
|
Color |
Customized |
|
Technique |
Pultrusion |
|
Mesh size |
38mm*38mm, 50mm*50mm, 40mm*40mm, or customized |
|
Thickness |
25mm, 30mm, 38mm, 50mm, etc |
|
Fiberglass content |
24% - 30% |
|
Sheet Size |
1220*3660mm or customized |
corrosion resistance, fire resistance and anti-skid
-
Frp grating walkway is a structural panel which uses high-strength E-Glass roving as reinforcing material, thermosetting resin as matrix and then casted and formed in a special metal mold.
-
FRP Molded Grating is widely used in oil industry, power engineering, water & waste water treatment, ocean survey as working floor, stair tread, trench cover, etc. and is an ideal loading frame for corrosion circumstances.
-
Our product passes a whole series of well known third party tests with the fire and mechanical properties, and the product sells well all over the world and has a good reputation.
Product advantage
--High strength ,Anti-aging
lt contains strong stress resistance, Lightweight, easy to cut and install.Excellent electrical insulation, no breakdown at 10KV voltage; No electromagnetism, which can be used on magnetic sensitive equipment.
--Corrosion Resistance
lt has excellent corrosion resistance to acid,alkali,organic solvent, salt and many othergas-liquid media.The special structure of GFRP grille also has anti-sliding and anti-fatigue properties.
--lnflaming Retarding
The flame propagation rate (ASTM e-84) of ordinaryflame retardant grating does not exceed 25;Flamepropagation rate of advanced flame retardant vinylgrille shall not exceed 10 oxygen index not less than 28(GB 8924)
--Color and size optional
The color can be selected arbitrarilyaccording to the requirements of cus-tomers,And flexible in size,convenient in cut-ting and stable in size.
About Yujinxiang
We are always at your service when you need
We offer a complete line of Powergrid brand products such as grating, covered grating, conductive grating, stair treads, stair tread covers, plates, and other accessories.And our high-quality fiberglass grating products are designed and manufactured to provide long lasting performance for industrial and offshore applications.
Since our inception, Yujinxiang has been dedicated to the ideal of making best value Fiberglass grating products in the world through the combination of wide selections, high quality and competitive prices.Welcome to contact us.
